Brand Name	Ximax
Colour	White
Material	Steel
Manufacturer Model No	282TP
Type	Radiator
Certifications Met	N/A
Country of Origin	N/A
BTU	1007 BTU
Connection Size	1/2 "
Construction Material (Plumbing)	Steel
Delta T	Delta T50°C
Finish Code	Finished to RAL 9003
Max. Working Pressure	4 bar
Max. Working Temperature	120 °C
Model Name	Oceanus
Mounting Orientation	Horizontally-Mounted
No. Of Sections	6
No. of Radiator Profiles	Single
Orientation	Horizontal
Power Output (Watts/Kw)	295 W
Product Height	445 mm
Product Width	600 mm
Projection from Wall (Std Bracket)	74 mm
Radiator Accessories Included	Brackets, Fixings, Plug & Vent Included
Radiator Coating & Finish	Powder-Coated
Radiator Colour	White
Radiator Height Band	300-599mm
Radiator Product Type	Designer
Radiator Water Content	1.6 Ltr
Radiator Width Band	501-700mm
Shape Orientation	Radiator is wider than it is tall
Suitable System	Suitable for Central Heating Systems
Test Pressure	5.2 bar
Total Product Weight	4.84 kg
Wall to Centre (Standard Bracket)	44 mm

Steel construction with high quality pre-treatment and powder-coated finish. Easy to install Wall fixings, plug and vent included Connection size: 1/2" Heat output calculated at Delta T50°C Pressure tested to 5.2 bar, max working pressure 4 bar Max. working temperature : 120°C Manufactured and tested to EN-442Dimensions are height by width.Stylish designer Rradiator with modern panel design. 10 year manufacturer's guarantee (T&Cs Apply). Suitable for hot water central heating systems. Projection from wall: 71 mm and wall to centre: 44 mm

Brand Name	Ximax
Colour	Anthracite
Material	Steel
Manufacturer Model No	TPH445600A
Type	Designer Radiators
Certifications Met	Manufactured and tested to EN-442
Certification	Manufactured and tested to EN-442
Max. Hot Water Temp	120°C
Warranty (years)	10 years
Range Name	Oxford
Depth (mm)	63mm
Width (mm)	600mm
Pack contents	Radiator, fixings, blank and air plug
Inlet Connection	1/2"
Finish	Gloss
Min. pressure (bar)	0.5 bar
Pipe Centres	600mm
BTU	1007
Max. pressure (bar)	4
Coating	Powder Coated
Radiator Style	Flat
BTU range	1001-2000
Fitted Depth	71mm
Radiator Profile	Single Panel
Number of Sections	6
Delta T	Delta T50°C
Radiator Orientation	Horizontal
Weight (Kg)	6.92KG

Brand Name	Ximax
Colour	Anthracite
Material	Steel
Coating	Epoxy polyester powder-coated
Connection size (imperial)	½"
Finish	Matt
Fitting type	Wall-mounted
Heat output	371W
Inlet position	Bottom
Maximum operating pressure	10bar
Maximum operating temperature	120°C
Model name/number	FORH1164600A
Outlet position	Bottom
Product depth	78mm
Product height	584mm
Product weight	6.94kg
Product width	600mm
Projection from the wall	92mm
Radiator type	Designer
Standard	EN 442
Thermostatic control	No thermostat control
Volume	5L
Wall to centre (with standard bracket)	52mm
Orientation	Horizontal
Product code	9006547652185

Brand Name	Ximax
Colour	Anthracite
Material	Steel
Coating	Epoxy polyester powder-coated
Connection size (imperial)	½"
Finish	Matt
Fitting type	Wall-mounted
Heat output	371W
Inlet position	Bottom
Maximum operating pressure	10bar
Maximum operating temperature	120°C
Model name/number	FORH1164600A
Outlet position	Bottom
Product depth	78mm
Product height	584mm
Product weight	6.94kg
Product width	600mm
Projection from the wall	92mm
Radiator type	Designer
Standard	EN 442
Thermostatic control	No thermostat control
Volume	5L
Wall to centre (with standard bracket)	52mm
Orientation	Horizontal
Product code	9006547652185
