Extra mobile. Extra stable.

Maximum stability of joints up to a dowel size of 14 x 140 mm
Patented routing principle unique to hand-held machines for accurate work with no kickbacks
Saves more time compared to a stationary machine
Stops that are quick and easy toadjust, for accurate results
System accessories compatible with both DOMINO jointers

Main applications
Solid wood furniture in frame and tunnel design
Frame construction of house doors and interior doors
Manufacture of tables and chairs
Creation of stable mitre joints
Folded and profiled door frames in furniture construction
Connection of wide cornices (e.g. plates)
Frame and stand constructions in non-supported timber structure (exterior and interior area)

Power consumption 720 WIdle engine speed 21000 min-1
Depth stop for routing depth 15-70 mm
DOMINO slot cutter Ø 8, 10, 12, 14 mm
Routing height adjuster with scale 10-50 mm
Movable stepped stop 10, 15, 20, 25, 30, 40 mm
Mitre routing 0-90 °Connection Ø d/e 27 mm
Weight 5,2 kg

DOMINO cutter D 12• support bracket• 2x dowel box• operation tool• ina SYSTAINER SYS 5 T-LOC
